For indoor prefabricated end butterfly-shaped drop optical cable

Butterfly drop cable for indoor wiring GJXV(H)/GJFV(H)
Product Description:
GJXV (GJXH) [Metal strengthening member, PVC (or LSZH) outer sheath, butterfly drop optical cable]
GJXFV(GJXFH)【Non-metallic strengthening member, tight sleeve coating, PVC (or LSZH) outer sheath, butterfly drop optical cable】
The optical cable structure is to place optical fibers or optical fiber ribbons on two parallel wire reinforcements and then squeeze a layer of LSZH (or PVC) sheath.
Executive standard:
YD/T 1997-2014 Butterfly Drop Optical Cable for Access Network

Features:
Optical cable has small outer diameter, light weight, and low construction cost;
Using cold connection technology, fast connection speed;
The optical cable has high resistance to flattening and tension, and the self-supporting structure can meet the flying span of less than 50 meters;
Using glass reinforced fiber rod (G-FRP), aramid fiber reinforced rod (K-FRP) or thin steel wire as reinforcement, the optical cable is soft and has good bending performance, ensuring that the bending radius of the optical cable meets the requirements;
Use LSZH or PVC flame-retardant materials to meet the flame retardant and environmental performance requirements of optical cables for indoor use; one optical fiber adopts bending loss insensitive optical fiber that meets the requirements of ITU-TG.657A&G.657B standards, with a minimum bending radius of 15mm or less .
